Elasticsearch Crib Sheet

4 minute read

General

All inputs are JSON documents, however the format does allows comments (C-style, /* */)
add ?v to include column headers in table output
add ?pretty to pretty print JSON output (rather than all on 1 line)
Important pages to read:
- https://www.elastic.co/guide/en/elasticsearch/reference/5.6/important-settings.html#path-settings

Indices

In Elastic Search terminology, the plural of ‘Index’ is ‘Indices’, NOT ‘Indexes’
There are a few properties that you must set correctly for indexes:
- mappings
- shard counts
- replicas, etc

Useful APIs

List indices:

GET _cat/indices?v

Display settings for all indices:

GET _settings/

Display settings for a specific index:

GET syslog-2018.12.08/_settings/

Display just some settings instead of all:

GET _settings/*shards,*replicas

Modify settings for a specific index:

PUT syslog-2018.12.08/_settings
{
  "index": {
    "number_of_replicas": "0",
    "number_of_shards": "1"
  }
}

NOTE: this will fail because both of those settings can only be modified for a closed index. See Templates section below for the correct way to set these.

Shards

By default, each index in Elasticsearch is allocated 5 primary shards and 1 replica which means that if you have at least two nodes in your cluster, your index will have 5 primary shards and another 5 replica shards (1 complete replica) for a total of 10 shards per index. — from https://www.elastic.co/guide/en/elasticsearch/reference/5.6/_basic_concepts.html
The number of shards should be chosen so that each shard is less than 50GB in size
There is a soft limit of 1000 shards per node (this is configurable)
If you’re on a single node, there is no point in having more than 1 shard per index
- Therefore you’ll need to change the default
You can monitor shard sizes using the /_cat/shards API:

List all shards
```
  GET _cat/shards?v
```

Replicas

If you leave this on the default of 1, everything will work fine, however your index status will NEVER go green, it will always stay yellow because you have asked for a replica but the cluster cannot deliver a replica if there is only 1 node.
Therefore if you have only 1 node, you should set replicas to 0 for all indexes.

Templates

A template is a set of settings and mappings that get used when creating a new index
- Therefore the template is only applied at index creation. If you modify a template, it doesn’t affect previously created indices
The API is /_template
See https://www.elastic.co/guide/en/elasticsearch/reference/5.6/indices-templates.html
Templates have a pattern which controls which indices they apply to. If the index name matches the template pattern, then the template is used when creating that index
- If multiple templates match an index name, then they all get applied. When there is a conflict, the ‘order’ fields of the templates control which wins. Higher value in order field wins.

Set default template

Check current values:

GET _template/default

Will return empty if there is no default

Set it:

POST _template/default
{
  "template": "*",
  "order": -1,
  "settings": {
    "number_of_shards": "1",
    "number_of_replicas": "0"
  }
}

Mappings

A mapping is kind of like a schema or table; it is a set of field definitions (this analogy breaks down quickly so don’t make too many assumptions based on it)
In the API URL, it is /<index>/<mapping> so /twitter/tweets references the ‘twitter’ index and the ‘tweets’ mapping
The mapping is defined when the index is created, and it can’t be modified afterwards.
- You can ADD a mapping to an index, but you can’t modify and existing mapping
- If you want to change a mapping, you need to create a new index with the new mapping, then use the reindex API to copy the data to the new index
Each index can have multiple mappings
- NOTE: This is being removed in Elastic Search 6.0
- You can use setting index.mapping.single_type: true to make v5.6 behave like 6.0+ will behave.
Different documents in an index can have different mappings
If a field name is used in multiple mappings, it must use the same type in each of them.
- E.g. if you have a field called ‘deleted’ date in one mapping, then you can’t have a field with same name that is a boolean in another mapping. It must be the same type on both mappings

Tips

For timeseries data, it’s a good idea to disable indexing of the numeric fields, since you’re like you want to aggregate those fields but unlikely to filter them. See https://www.elastic.co/guide/en/elasticsearch/reference/5.6/dynamic-templates.html#_time_series

Specific Tasks

Create and Delete indices

View index:

GET tempmon-2016*

Create index:

PUT tempmon-2016

Delete index:

DELETE tempmon-2016

Combine indices

e.g. Combine tempmon-2016.10, tempmon-2016.11, tempmon-2016.12 into a single index tempmon-2016

View the indices:

GET tempmon-2016*

Ensure there is an appropriate template that sets things like shards and replicas. Test the template works by creating and then viewing a new index (just give it a random name then delete it)

Do the reindex:

POST _reindex?pretty
{
    "conflicts": "proceed",
    "source": {
        "index": "tempmon-2016*"
    },
    "dest": {
        "index": "tempmon-2016",
        "op_type": "create"
    }
}

NOTE: This can take a while to run, so if you run it in Kibana Dev Tools it will probably time out. However, the reindex will continue in the background. Alternatively you can run the command from the terminal. Click the spanner in Kibana and “Copy as cURL” to get it in the right format.

To monitor the creation of the new index:

GET tempmon-2017/_stats

The total document count is:

  "_all": {
    "primaries": {
      "docs": {
        "count": 243157,

You can get status for multiple indices like this:

GET tempmon-2017.*/_stats

this will list all matching indices, but at the top will be the _all section which aggregates all the indices and should match the above number.

Finally, delete the old indices:

DELETE tempmon-2017.*
